Last year I purchased a Solent 23cm Amateur Television (ATV) transmitter. Although working, it needed a bit of a tidy up. Whilst tidying things up I decided to make a few modifications and place the transmitter in a new case too.
MiniTiouner hardware was designed by Jean-Pierre F6DZP and is a DVB-S/S2 USB receiver that works with MiniTioune software. It covers 143MHz to 2450MHz and was designed for use by Amateur Television (ATV) operators.
Like other amateur radio operators I want to use the MiniTiouner and software to receive transmissions from the Es’hail 2 QO-100 geostationary satellite.
I built my MiniTiouner (phase 1) in January 2019 but due to work commitments have just got round to using it.
In October 2018 I started using a Comtech 23cm transmitter for my ATV operations. Rather than use the 8-way dip switches to tune the transmitter, I decided to work on a project to develop a rotary LCD tuner using an Arduino Uno as the micro-controller. This article shows how I did it, including the code.
On 19th January 2017, I started the process of making a printed circuit board for my 23cm amplifier project. I was extremely pleased with the results so thought I would write an article and make a video that shows how I did it.
